Name: LOW INPUT / OUTPUT 1.5 A LDO REG
Brand: Nisshinbo Micro Devices Inc.
SKU: RP120Z001D-E2-F
Availability: OutOfStock
Rating: 4.7 (3 reviews)

RP120Z001D-E2-F

Price: Price on request ~~0.00 $~~ (Excl. VAT)

Brand :Nisshinbo Micro Devices Inc.
Product SKU :RP120Z001D-E2-F
Description :LOW INPUT / OUTPUT 1.5 A LDO REG
Condition: Original New

Product Condition Guide

Original New Current

100% original and unused. 1-year warranty.

Used

Tested working. 90-day warranty.

Refurbished

Restored and tested. 90-day warranty.

Pulled

Removed and tested. 90-day warranty.

New Surplus

Unused excess stock, packaging may vary. 1-year warranty.

| Warranty: 1 Year
Quantity : In Stock () Stock on request
Datasheet :RP120Z001D-E2-F Datasheet
ECAD Model :

ISO 9001:2015 Certified No. 80426Q00050R000

Specification
Product Details
Reviews

MfrNisshinbo Micro Devices Inc.
Series-
PackageTape & Reel (TR)
Product StatusActive
Output ConfigurationPositive
Output TypeAdjustable
Number of Regulators1
Voltage - Input (Max)5.5V
Voltage - Output (Min/Fixed)0.6V
Voltage - Output (Max)3.6V
Voltage Dropout (Max)0.168V @ 1.5A
Current - Output1.5A
Current - Quiescent (Iq)2.8 µA
PSRR90dB ~ 60dB (1kHz ~ 100kHz)
Control FeaturesCurrent Limit, Enable, Soft Start
Protection FeaturesOver Current, Over Temperature, Short Circuit, Under Voltage Lockout (UVLO)
Operating Temperature-40°C ~ 85°C (TA)
Mounting TypeSurface Mount
Package / Case6-XFBGA, WLCSP
Supplier Device PackageWLCSP-6-P11
