Name: CONN HEADER VERT 8POS 3.96MM
Brand: Molex
SKU: 0026503080
Availability: OutOfStock
Rating: 4.7 (3 reviews)

0026503080

Price: Price on request ~~0.00 $~~ (Excl. VAT)

Brand :Molex
Product SKU :0026503080
Description :CONN HEADER VERT 8POS 3.96MM
Condition: Original New

Product Condition Guide

Original New Current

100% original and unused. 1-year warranty.

Used

Tested working. 90-day warranty.

Refurbished

Restored and tested. 90-day warranty.

Pulled

Removed and tested. 90-day warranty.

New Surplus

Unused excess stock, packaging may vary. 1-year warranty.

| Warranty: 1 Year
Quantity : In Stock () Stock on request
Datasheet :0026503080 Datasheet
ECAD Model :

ISO 9001:2015 Certified No. 80426Q00050R000

MfrMolex
SeriesKK396, 41671
PackageBulk
Product StatusActive
Connector TypeHeader, Breakaway
Contact TypeMale Pin
Pitch - Mating0.156" (3.96mm)
Number of Positions8
Number of Rows1
Row Spacing - Mating-
Number of Positions Loaded7
StyleBoard to Board or Cable
ShroudingShrouded - 1 Wall
Mounting TypeThrough Hole
TerminationSolder
Fastening TypeFriction Lock
Contact Length - Mating0.450" (11.43mm)
Contact Length - Post0.172" (4.37mm)
Overall Contact Length0.750" (19.05mm)
Insulation Height0.500" (12.70mm)
Contact ShapeSquare
Contact Finish - MatingTin
Contact Finish Thickness - Mating60.0µin (1.52µm)
Contact Finish - PostTin
Contact MaterialBrass
Insulation MaterialPolyester
Features-
Operating Temperature-
Ingress Protection-
Material Flammability RatingUL94 V-0
Insulation ColorBlack
Current Rating (Amps)-
Voltage Rating-
Mated Stacking Heights-
Contact Finish Thickness - Post60.0µin (1.52µm)
ApplicationsAutomotive, General Purpose, Industrial, Medical, Telecommunications
Base Product Number002650
