MOSFET P-CH 40V 7.2A PWRDI3333-8

DMP4025SFGQ-7

Price: 0.62 $ ~~0.62 $~~ (Excl. VAT)

Brand :Diodes Incorporated
Product SKU :DMP4025SFGQ-7
Description :MOSFET P-CH 40V 7.2A PWRDI3333-8
Condition: Original New

Product Condition Guide

Original New Current

100% original and unused. 1-year warranty.

Used

Tested working. 90-day warranty.

Refurbished

Restored and tested. 90-day warranty.

Pulled

Removed and tested. 90-day warranty.

New Surplus

Unused excess stock, packaging may vary. 1-year warranty.

| Warranty: 1 Year
Quantity : In Stock () Stock on request
Datasheet :DMP4025SFGQ-7 Datasheet
ECAD Model :

ISO 9001:2015 Certified No. 80426Q00050R000

Specification
Product Details
Reviews

MfrDiodes Incorporated
SeriesAutomotive, AEC-Q101
PackageTape & Reel (TR), Cut Tape (CT), Digi-Reel®
Product StatusActive
FET TypeP-Channel
TechnologyMOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)40 V
Current - Continuous Drain (Id) @ 25°C7.2A (Ta)
Drive Voltage (Max Rds On, Min Rds On)4.5V, 10V
Rds On (Max) @ Id, Vgs25mOhm @ 3A, 10V
Vgs(th) (Max) @ Id1.8V @ 250µA
Gate Charge (Qg) (Max) @ Vgs33.7 nC @ 10 V
Vgs (Max)±20V
Input Capacitance (Ciss) (Max) @ Vds1643 pF @ 20 V
FET Feature-
Power Dissipation (Max)810mW (Ta)
Operating Temperature-55°C ~ 150°C (TJ)
Mounting TypeSurface Mount
Supplier Device PackagePowerDI3333-8
Package / Case8-PowerVDFN
Base Product NumberDMP4025
